Interacting with CAE Software
Simcenter STAR-CCM+ can interact with a wide range of other computer-aided engineering (CAE) software. This interaction includes import/export of mesh and solution data as well as coupling capabilities for multiphysics simulations.
- File Import and Export
  Simcenter STAR-CCM+ allows you to import mesh and solution data from other CAE packages using files. You can also export such data from Simcenter STAR-CCM+ for use in external software.
- File-Based Coupling (through Imported CAE Model)
  File-based coupling is a method used to couple Simcenter STAR-CCM+ with another CAE code via external files stored in the computer memory.
- Rotor Blade Aeroelasticity
  Rotor Blade Aeroelasticity (RBA) simulations model the aerodynamic performance of elastic rotor blades using displacement and twist data from external files. You can create these data files in multi-body dynamics software such as RCAS, CAMRAD-II, DYMORE, and FLIGHTLAB. Typical RBA applications include urban air vehicle rotors, wind turbines, and helicopter rotors.
- Simcenter STAR-CCM+ to Simcenter STAR-CCM+ Co-Simulation
  Simcenter STAR-CCM+ allows you to couple two running simulations together in a co-simulation analysis. The Simcenter STAR-CCM+ to Simcenter STAR-CCM+ co-simulation capability targets analyses involving conjugate heat transfer (CHT), fluid-structure interaction (FSI), and exchange of any scalar or vector fields across the coupled boundaries or regions.
- Simcenter Nastran Co-Simulation
  For fluid-structure interaction (FSI) analyses, you can couple Simcenter STAR-CCM+ and Simcenter Nastran in a co-simulation analysis.
- Simcenter Amesim Co-Simulation
  Simcenter STAR-CCM+ allows for two-way co-simulation with Simcenter Amesim, which is used for modeling dynamic systems.
- FMU Co-Simulation
  Simcenter STAR-CCM+ allows you to import Functional Mock-up Unit (FMU) models for co-simulation. An FMU is a time-dependent model, typically representing a dynamic network, that is written according to the Functional Mock-up Interface (FMI) standard. The FMI standard is a software-independent standard that provides an interface for coupling simulation software.
- Abaqus Co-Simulation
  The co-simulation technique can be used to solve complex fluid-structure interaction (FSI) problems by coupling Abaqus and Simcenter STAR-CCM+. Mechanical and/or thermal fields can be exchanged across the fluid-structure interface.
- GT-SUITE Co-Simulation
  Simcenter STAR-CCM+ allows for two-way co-simulation with GT-SUITE, a multiphysics simulation tool from Gamma Technologies. GT-SUITE provides a modeling framework for the design and analysis of engineering systems, such as engines, vehicles, and thermal-hydraulic networks.
- Reacting Channel Coupling
  The Reacting Channel Coupling feature provides the ability for exchange of data between three-dimensional Simcenter STAR-CCM+ and the one-dimensional Plug Flow Reactor which uses the CVODE solver. You can use the Reacting Channel co-simulation model in Simcenter STAR-CCM+ to solve reacting flow simulations in tubular heat exchangers with channels that are long and thin.
- Generic Launcher
  Simcenter STAR-CCM+ provides a generic launcher for external applications that allows you to launch any application or file at a specified time interval during a simulation.
- Co-Simulation API
  Simcenter STAR-CCM+ provides an Application Programming Interface (API) that allows you to write partner code that exchanges data with a running Simcenter STAR-CCM+ simulation. As the partner code can be part of any other application that supports linking to a flat C library, the co-simulation API extends the range of co-simulation scenarios possible with Simcenter STAR-CCM+.
  - Co-Simulation API Overview
    The following sections provide information on how to couple your code with Simcenter STAR-CCM+ through the Simcenter STAR-CCM+ Co-Simulation API. For details on the available API functions and options, refer to the Co-Simulation API Online Help. You can access the Online Help from the Simcenter STAR-CCM+ interface by selecting Help > Co-simulation API.
  - Preparing Your Code for Co-Simulation with Simcenter STAR-CCM+
    Your program couples with Simcenter STAR-CCM+ through the Simcenter STAR-CCM+ API server, which is a Simcenter STAR-CCM+ simulation that represents your program. You set up and communicate with the Simcenter STAR-CCM+ API server through the Co-Simulation API library. The Simcenter STAR-CCM+ API server couples with other Simcenter STAR-CCM+ simulations using Simcenter STAR-CCM+ to Simcenter STAR-CCM+ Co-Simulation.
  - Running a Co-Simulation between Partner Code and Simcenter STAR-CCM+
- Data Mappers
  In Simcenter STAR-CCM+, data mappers allow you to interpolate field data available either on a source mesh or on a source table to a target mesh representation, so that the mapped fields can be used for applying boundary or volume conditions on the target mesh.
- Coordinate Cell Clustering
  Simcenter STAR-CCM+ allows you to group mesh cells into clusters, based on their position with respect to a specified coordinate system, and provides a field index for querying values based on cluster. You can create threshold reports based on these clusters of cells.

Co-Simulation API

Simcenter STAR-CCM+ provides an Application Programming Interface (API) that allows you to write partner code that exchanges data with a running Simcenter STAR-CCM+ simulation. As the partner code can be part of any other application that supports linking to a flat C library, the co-simulation API extends the range of co-simulation scenarios possible with Simcenter STAR-CCM+.

When initialized, the Co-Simulation API launches a companion Simcenter STAR-CCM+ API server alongside the partner software. During co-simulation, the companion Simcenter STAR-CCM+ API server communicates with other Simcenter STAR-CCM+ servers using the same protocols as a co-simulation between two Simcenter STAR-CCM+ simulations. Partner software makes calls into the Co-Simulation API library to receive data from, and transfer data to, the companion Simcenter STAR-CCM+ API server.

Each release of the Co-Simulation API is identified with a unique number, that is, the API version. Typically, new versions of the Co-Simulation API are released less frequently than new versions of Simcenter STAR-CCM+. To facilitate the transition to newer API versions and to prolong backwards compatibility, each Simcenter STAR-CCM+ release supports multiple versions of the Co-Simulation API. You are advised to keep your program up-to-date with the latest version of the Co-Simulation API, as older API versions may be retired in future Simcenter STAR-CCM+ releases.

The following sections describe the latest version of the API. For more information on older API versions, refer to the User Guide of previous Simcenter STAR-CCM+ releases.
