Running the Simulation

Preparation of the simulation is now complete, and the simulation can be run.

To run the simulation:

Click (Run) in the Solution toolbar.

The solution progress is displayed in the Output window. The Residuals display is created automatically in the Graphics window and shows the progress of the solvers.

During the run, you can stop the process by clicking (Stop) on the toolbar. If you do stop the simulation, you can click (Run) to resume it. If left alone, the simulation continues until 20 seconds of physical time is complete.

While the simulation is running, you can click the tabs at the top of the Graphics window to view scenes and plots.

You can check the Normalized Mass Flow Monitor while the solution is running.

Double-click Plots > Normalized Mass Flow Monitor Plot to display the results in the Graphics window.
When the simulation has finished running, save it.
