Using the Mass-Weighted Mixture

The mass-weighted mixture method calculates a given mixture property by mass-weighting the component property values.

For example, mixture property $ϕ_{m i x}$ is:

Figure 1. EQUATION_DISPLAY

ϕ_{m i x} = \sum_{i = 1}^{N} {y_{i} ϕ}_{i}

(137)

where $y_{i}$ and $ϕ_{i}$ are the mass fraction and property values of mixture component- $i$ and $N$ is the total number of components in the mixture.

Mass-Weighted Mixture Properties

None
